Calling Business Central APIs Without a Client Secret

Intro

We’re doing more with Azure resources. I expect that you are too. Especially Static Web Apps and Azure Functions that we need to be able to call back into the Business Central and Dataverse APIs.

To authenticate with Business Central we would typically:

1. create an app registration in Azure
2. add Business Central APIs permissions to the app registration
3. create an Entra Application in Business Central and assign permission sets to it
4. create a client secret
5. use the client id and secret to obtain an OAuth token to call the BC API

That’s all good and well, but using secrets can be problematic. They expire, and when they do they need to be regenerated and updated in the key vault / environment variable / variable group / wherever you are storing it. There is also the risk that the secret ends up in the hands of some muppet that you’d rather it hadn’t and they are able to call the API.

It would be better if we had a solution that didn’t rely on client secrets.

Overview

For the Dataverse API this is pretty straight forward. We can assign a managed identity to the Azure resource that needs to call the API (an Azure function in this case). That managed identity has a client id which can be used to create an App user in the target Power Platform environment.

1. The Azure function obtains a token for the managed identity which it has been assigned, for the target Power Platform environment
2. Entra gives it an access token
3. The Dataverse API allows the CRUD operations on the tables because the manged identity exists as an app user and has security roles assigned to it

For Business Central, it is a little trickier. It seems like Business Central does not support managed identities (or at least, I couldn’t see how). The overview looks more like this:

Let’s go through the pieces of the jigsaw.

Goal

We’ve got an API page published in Business Central. We need to be able to call this from an Azure function (which in our case is acting as the API for a Static Web App). We don’t want to rely on the Azure function needing a client secret to authenticate with BC.

App Registration

For service-to-service authentication we are going to need an app registration. It seems like there is no way around that at the moment (please tell me I’m wrong though).

The app registration is granted permission to the Business Central API(s) and admin consent is granted by an admin.

An Entra Application record is created in Business Central which creates a user for that application and assigns permission sets to it. So far so familiar (if not, take a look here: https://learn.microsoft.com/en-us/dynamics365/business-central/dev-itpro/administration/automation-apis-using-s2s-authentication)

Managed Identity

The managed identity provides a way for the Azure function to obtain an access token without the need for client credentials. The identity can be assigned under the Settings menu of the Function app in the Azure portal.

My Azure function is running Node.js so I’m using the Azure Identity package to get the token (https://learn.microsoft.com/en-us/javascript/api/overview/azure/identity-readme?view=azure-node-latest). There is a NuGet package for doing the same thing in .Net functions. An environment variable, AZURE_CLIENT_ID holds the client id of the managed identity.

const credential = new ManagedIdentityCredential({ clientId: process.env.AZURE_CLIENT_ID });
const token = await credential.getToken("api://AzureADTokenExchange");

Token Exchange

Here’s the tricky part.

• The Azure function has obtained a token as its managed identity, but
• It is the app registration which has permissions in BC, not the managed identity

If the Azure function tries to authenticate with Business Central with that token it will be told to clear off. Unauthorised.

We need to exchange the token we’ve already got for a token issued for the app registration. How do we do that? Enter Federated Credentials (https://learn.microsoft.com/en-us/graph/api/resources/federatedidentitycredentials-overview?view=graph-rest-1.0)

This provides a way for external code to obtain tokens for the app registration. We can use the token we’ve already obtained to get another that will give us permission to the Business Central API.

const tokenEndpoint = process.env.BC_API_TOKEN_URI!;
const scope = "https://api.businesscentral.dynamics.com/.default";
const appRegistrationTokenResponse = await fetch(tokenEndpoint, {
    method: 'POST',
    body: `grant_type=client_credentials&scope=${scope}&client_id=${process.env.BC_API_USER}&client_assertion_type=urn:ietf:params:oauth:client-assertion-type:jwt-bearer&client_assertion=${token.token}`,
    headers: {
        'Content-Type': 'application/x-www-form-urlencoded',
    },
});

This is a request to the token endpoint, requesting a token for the client id of the app registration and passing the token which we already have for the managed identity (the client_assertion parameter).

Federated Credential Setup

Why should Entra issue us a token for the app registration on the basis that we have a token for a different client id?

We need to establish a trust between the two to tell Entra that having a token

• issued by a certain authority (issuer), and
• having a particular subject

is enough to trust that you can have a token for the app registration.

Kind of like if Kermit has opened an exclusive new restaurant in town and everyone wants to get a table. You don’t have a reservation, but you do have a personalised, signed note from Elmo. Because Kermit:

• can see the note is made out to you (the subject),
• is from Elmo (the issuer), and
• he trusts Elmo

then he writes his own note and gives it to you telling the staff to let you in. You trot along to the restaurant, waving your note and are granted access.

The Federated Credential has these three elements and is set up on the App Registration in the Azure Portal.

From the Overview of the App Registration click on “Add a certificate or secret” like you would normally to create a client secret. Now click on Federated credentials and Add credential.

On the following page you are prompted to select the scenario. My scenario is Managed identity. You are prompted to select the managed identity that you want to work with.

The issuer is automatically populated with the v2.0 endpoint which tokens for the managed identity will be acquired from.

The subject identifier is automatically populated with the client id of the managed identity. This will be the subject of a token that is acquired for the managed identity. You can change these values, but it shouldn’t be necessary.

You can check these values by examining the managed identity token in a tool like https://jwt.io/.

Finally, you are prompted to give this federated credential a name and set the audience. The default value is api://AzureADTokenExchange. Notice that this is the same value that was passed to credential.getToken when retrieving the managed identity token.

Conclusion

And that is it.

1. The front end (hosted in Azure Static Web Apps) calls the backend (a linked Azure function app)
2. The Azure function obtains a token for the managed identity that it is associated with
3. It then uses that token to obtain another token for the app registration
4. The second token can be used to call the Business Central API because the app registration has been configured on the Microsoft Entra Applications page in BC

If that sounds like a lot to set up – especially if you are doing it more than once, then maybe you are right. That is where Bicep/ARM templates come in. Maybe more of that in another post.
